Ultrafine Pulverizer
Ultrafine pulverizer that grinds dry materials to fine powder by high-speed impact and shear, with low-temperature operation for heat-sensitive feeds.
Overview
The WFJ ultrafine pulverizer grinds dry materials to a fine or ultrafine powder through high-speed impact and shear between a rotating toothed disc and a fixed toothed ring. Airflow and a classifier control the particle size, and the cooling effect of the airflow makes it well suited to heat-sensitive and fibrous materials.
Features
- Ultrafine output with adjustable fineness
- Low-temperature grinding that protects heat-sensitive materials
- Stainless-steel contact parts, easy to clean and GMP-friendly
- Enclosed, low-dust operation
- High grinding efficiency
Working Principle
Material enters the chamber between a high-speed rotating toothed disc and a stationary toothed ring, where intense impact, shear and friction reduce it to fine powder. Airflow carries the powder to a collector and classifier, while oversized particles are returned for further grinding.
Technical Specifications
| Model | WFJ-15 | WFJ-18 | WFJ-36 |
|---|---|---|---|
| Production Capacity (kg/h) | 10-200 | 20-450 | 60-1000 |
| Feed Particle Size (mm) | <10< span=""> | <12< span=""> | <15< span=""> |
| Output Granularity (mesh) | 80-320 | 80-450 | 80-450 |
| Total Power (kW) | 13.5 | 17.5 | 38 |
| Main Speed (r/min) | 4500 | 4480 | 4000 |
| Overall Dimensions (L×W×H) (mm) | 4200×1200×2800 | 4700×1250×2900 | 9000×1500×3800 |
Applications
Dry, brittle and fibrous materials in the pharmaceutical, food, chemical and spice industries.
