Universal Grinder
Universal grinder that reduces dry, brittle materials to powder by high-speed impact, with an interchangeable screen setting the fineness.
Overview
The 30B universal grinder reduces dry, brittle materials to powder by high-speed impact between rotating blades and a fixed toothed lining. An interchangeable screen sets the fineness, making it a compact, versatile general-purpose mill.
Features
- High-speed impact grinding with screen-set fineness
- Stainless-steel contact parts
- Compact and easy to disassemble and clean
- Built-in fan that reduces heat during grinding
- Wide range of suitable materials
Working Principle
Material in the grinding chamber is struck by high-speed rotating blades against a toothed lining and reduced by repeated impact and shear. Once fine enough to pass the screen, it is discharged, while coarser particles remain for further grinding.
Technical Specifications
| Model | 20B-C | 30B-C | 40B-C | 60B-C |
|---|---|---|---|---|
| Production Capacity (kg/h) | 60-150 | 100-300 | 160-800 | 500-1500 |
| Spindle Speed (r.p.m) | 4500 | 3800 | 3400 | 2800 |
| Feed Granularity (mm) | 6 | 10 | 12 | 15 |
| Product Fineness (mesh) | 60-120 | 60-120 | 60-120 | 60-120 |
| Motor Power (kW) | 4 | 5.5 | 11 | 15 |
| Dust-Collection Fan (kW) | 1.5 | 1.5 | 1.5 | 2.2 |
| Overall Dimensions (L×W×H) (mm) | 1100x600x1650 | 1200x650x1650 | 1350x700x1700 | 1550x1000x1750 |
Applications
Dry, brittle materials in the pharmaceutical, chemical, food, spice and feed industries.
