High-Efficiency Fluid Bed Dryer
High-efficiency batch fluid bed dryer with a stirred hopper and closed negative-pressure operation for fast, uniform GMP drying.
Overview
The high-efficiency fluid bed dryer is a batch unit in which heated, purified air is drawn up from below through a perforated hopper plate. Stirring and negative pressure create a fluidized state in the working chamber, so moisture evaporates rapidly and is carried off by the exhaust.
Features
- Round bed structure that avoids dead corners
- Stirring in the hopper prevents agglomeration of wet material and channeling
- Tipping discharge for fast, thorough emptying; optional automatic feed and discharge
- Closed negative-pressure operation with filtered gas, easy to clean and GMP-compliant
- Fast drying with uniform temperature, typically 20-30 minutes per batch
Working Principle
Air is heated and purified, then drawn upward by an induced-draft fan through the perforated plate of the hopper. Inside the chamber, stirring combined with negative pressure forms a fluidized layer of material. Moisture evaporates quickly and is carried away with the exhaust gas, drying the material in a single batch.
Technical Specifications
| Feed Capacity (kg) | 60 | 100 | 120 | 150 | 200 | 300 | 500 |
|---|---|---|---|---|---|---|---|
| Fan Air Volume (m³/h) | 2361 | 3488 | 4000 | 4901 | 6032 | 7800 | 10800 |
| Fan Pressure (mmH2O) | 594 | 533 | 533 | 679 | 787 | 950 | 950 |
| Power (kW) | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 45 |
| Stirring Power (kW) | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 1.5 | 2.2 |
| Stirring Speed (r.p.m) | 11 | ||||||
| Steam Consumption (kg/h) | 141 | 170 | 170 | 240 | 282 | 366 | 451 |
| Operating Time (min) | 15-30 | ||||||
| Main Unit Height, Square (mm) | 2750 | 2850 | 2850 | 2900 | 3100 | 3300 | 3650 |
| Main Unit Height, Round (mm) | 2700 | 2900 | 2900 | 2900 | 3100 | 3600 | 3850 |
Applications
Wet granules and powders in pharmaceutical, food, feed and chemical sectors, including extruded, swinging and wet-mixed granules, large and sticky lumps, and volume-changing materials such as konjac and polyacrylamide.
